Bently Nevada 3300 XL 50 mm Proximity Probe 330876 with AISI 304 SST Case

Name: Bently Nevada 3300 XL 50 mm Proximity Probe 330876 with AISI 304 SST Case
Brand: Bently Nevada
Price: 1 USD

Buy cheap Bently Nevada 3300 XL 50 mm Proximity Probe 330876 with AISI 304 SST Case product

Brand Name : Bently Nevada

Model Number : 330876-01-90-00-00

Certification : CE

Place of Origin : USA

MOQ : 1pc

Price : negotiable

Payment Terms : T/T

Supply Ability : 100pcs per month

Delivery Time : 12-16weeks

Packaging Details : standard carton packing

Probe Tip Material : Polyphenylene Sulfide (PPS)

Probe Case Material : AISI 304 stainless steel (SST).

Proximitor Sensor Material : A380 aluminum

Sliding Bracket Material : Anodized aluminum and stainless steel

System Length : 5 or 9 metres including extension cable

Probe and Extension Cable Armor (optional) : Flexible SST with PFA outer jacket.

Contact Now

Bently Nevada 3300 XL 50 mm Proximity Probe 330876

The 3300 XL 50 mm Transducer System consists of a separate 50 mm probe, an extension cable, and a 3300 XL 50 mm Proximitor Sensor. The large diameter coil gives this system a maximum linear range of 27.9 mm (1100 mils), the longest linear range of our eddy current transducer line. This linear range makes the 3300 XL 50 mm Transducer System ideal for measuring the differential expansion (DE) or rotor expansion (RX) of large steam turbine generators that results from the difference in growth rates between the turbine rotor and the machine stator (casing).

3300 XL 50 mm Proximity Probe

330876-AA-BB-CC-DD

A: Probe Case Type Option
01	½-20 Thread
02	M14x1.5 Thread
03	Smooth 1.99 in dia - Side Exit
B: Total Length Option
10	1.0 metre (3.3 feet)
50	5.0 metres (16.4 feet)
90	9.0 metres (29.5 feet)
C: ArmorOption
00	High Temperature FluidLoc Cable
01	High Temperature FluidLoc Cable with Armor
D: Agency Approval Option
00	No Approvals
05	Multiple Approvals
